Specifications
| Model | PLC-435M-AU-IR3/PM |
|---|---|
| Image Sensor | 1/2.7 "CMOS |
| Image Size | 2880×1620 |
| Electronic Shutter | 1/1s ~ 1/100000s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.007 lux @F1.6, AGC ON 0 lux with IR |
| Lens | 2.8mm@F1.6, Horizontal FoV: 110.5°, Vertical FoV: 57°, Diagonal FoV: 131° 3.6mm@F1.6, Horizontal FoV: 91.5°, Vertical FoV: 49.5°, Diagonal FoV: 107° |
| Focus | Fixed |
| Lens Mount | M12 |
| Day & Night | ICR |
| Wide Dynamic Range | 120dB |
| BLC | Yes |
| HLC | Yes |
| Digital NR | Yes |
| Angle Adjustment | Pan: 0°~360° Tilt: 0°~80° Rotation: 0°~360° |
| Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264 Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| H.265 Compression Standard | Main Profile@Level4.1 High Tier |
| Resolution | 5MP (2880×1620), 4MP (2560×1440), 3MP (2304×1296), 1080P (1920×1080), 720P (1280×720), D1, 480×240, CIF |
| Main Stream | 60Hz: 5MP (1~20fps) / 4MP / 3MP / 1080P / 720P (1~30fps) 50Hz: 5MP (1~20fps) / 4MP / 3MP / 1080P / 720P (1~25fps) |
| Sub Stream | 60Hz: 720P / D1 / CIF (1~30fps) 50Hz: 720P / D1 / CIF (1~25fps) |
| Third Stream | 60Hz: D1/480×240 / CIF (1~30fps) 50Hz: D1/480×240 / CIF (1~25fps) |
| Bit Rate | 64 Kbps ~ 8 Mbps |
| Bit Rate Type | VBR / CBR |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Remote Monitoring | Web browser / Pollo NVR / PVMS Plus / Pollo Live Plus mobile app |
| Web Browser | IE (plug-in required) / Google Chrome / Edge / Firefox / Safari |
| Online Connection | Support simultaneous monitoring for up to 10 users Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, RTMP, HTTP, HTTPs, QoS |
| Interface Protocol | ONVIF |
| Storage | Network remote storage micro-SD card storage |
| Smart Alarm | Motion detection, SD card full, SD card error |
| Smart Event | Video Exception (scene change, video blur and video cast detection), line crossing detection, region intrusion detection, abandoned/missing object detection |
| General Function | Watermark, IP address filtering, video mask, heartbeat, illegal login lock, corridor pattern |
| PoE | Yes |
| IR Distance | 20 ~ 30 m |
| Ingress Protection | IP67 |
| Network | RJ45 |
| Video Output | No |
| Audio | 1CH audio input 1CH built-in MIC |
| Storage | Built-in micro-SD card slot, up to 256GB |
| Reset | Yes |
| Power Supply | DC12V/PoE |
| Power Consumption | < 6W |
| Operating Environment | -30°C ~ 60°C (-22°F ~ 140°F) Humidity: less than 95% (non-condensing) |
| Storage Environment | -30°C ~ 65°C (-22°F ~ 149°F), Humidity: less than 95% (non-condensing) |
| Dimensions (mm) | 167.5 × 74.5 × 74.5 |
| Weight (net) | Approx. 0.38kg |
| Installation | Ceiling mounting Wall mounting |
| Certificate | CE, FCC |
| Environmental Protection | Complies with Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH (EC1907/2006) |
