Specifications
| Model | PLC-435M-MZ-IR5/PM |
|---|---|
| Image Sensor | 1/2.7" CMOS |
| Image Size | 2592×1944 |
| Electronic Shutter | 1/30 s ~ 1/100000 s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.008 lux@F1.4, AGC ON 0 lux with IR 0.0045 lux@F1.2, AGC ON 0 lux with IR |
| Lens | 2.8~12mm@F1.4, motorized |
| Field of View | Horizontal: 92.7°~29.8° Vertical: 76.4°~22.6 Diagonal: 105.4°~36.8° |
| Lens Mount | Ø14 |
| Day & Night | ICR |
| Wide Dynamic Range | 120dB |
| BLC | Yes |
| HLC | Yes |
| Defog | Yes |
| Digital NR | 3D DNR |
| Angle Adjustment | Pan: 0°~360° Tilt: 0°~80° Rotation: 0°~360° |
| Video Compression | Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264 / MJPEG |
| H.264 Compression Standard | Baseline Profile / Main Profile / High Profile |
| Resolution | 5MP (2592×1944), 4MP (2592×1520), 2K (2560×1440), 3MP (2304×1296), 1080P (1920×1080), 720P (1280×720), D1, CIF, 480×240 |
| Main Stream | 5MP / 4MP / 2K / 3MP / 1080P / 720P (60Hz: 1 ~ 30fps 50Hz: 1~25fps) HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps 50Hz: 1~50fps) |
| Sub Stream | 720P/D1/CIF/480×240 (60Hz: 1 ~ 30fps 50Hz: 1~25fps) |
| Third Stream | D1/CIF/480×240 (60Hz: 1 ~ 30fps 50Hz: 1~25fps) |
| Bit Rate | 64 Kbps ~ 8 Mbps |
| Bit Rate Type | VBR / CBR |
| Audio Compression | G711A / U |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR, etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Network | RJ45 |
| Video Output | No |
| Audio | 1CH audio input |
| Storage | Built-in micro-SD card slot up to 128GB |
| Reset | Yes |
| Remote Monitoring | Web browsing, CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 10 users Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, ICMP, IGMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS |
| Video Abnormality | Scene change detection, video blur detection, video colour cast detection |
| Perimeter Detection | Line crossing detection (human/vehicle classification) Region intrusion/entrance/exiting detection (human/vehicle classification |
| Sound Light Warning | Yes |
| Interface Protocol | ONVIF |
| Storage | Network remote storage micro-SD card storage |
| Smart Alarm | Motion detection, SD card error, SD card full, IP address conflict, Cable connection |
| General Function | Watermark, IP address filtering, video mask, heartbeat, password protection, non-photosensitive switch, image distortion correction |
| PoE | Yes, IEEE802.3af |
| IR Distance | 30 ~ 50 m |
| Ingress Protection | IP67 |
| Power Supply | DC12V/PoE |
| Power Consumption | < 11W |
| Operating Environment | -30°C ~ 60°C (-22°F ~ 140°F) E42Humidity: less than 95% non condensing |
| Dimensions (mm) | 217.7 × 80.5 × 80.5 |
| Weight (net) | Approx. 0.65kg |
| Installation | Ceiling mounting Wall mounting |
| Certificate | CE, FCC |
| Environmental Protection | Complies with Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH (EC1907/2006) |
