Specifications
| Model | PLC-435M-AUK-IR3/PM |
|---|---|
| Image Sensor | 1/2.7 "CMOS |
| Image Size | 2592×1944 |
| Electronic Shutter | 1/3s ~ 1/100000 s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.02 lux@F1.6, AGC ON 0 lux with IR |
| Lens | 2.8 mm@F1.6, horizontal FoV: 99.87° vertical FoV: 70.36° diagonal FoV: 120° |
| Focus | Fixed |
| Lens Mount | M12 |
| Day & Night | ICR |
| Wide Dynamic Range | 120dB |
| BLC | Yes |
| HLC | Yes |
| Defog | Yes |
| Digital NR | 3D DNR |
| Angle Adjustment | Pan: 0°~355°, Tilt: 0°~67°, Rotation: 0°~355° |
| Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264 Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| H.264 Compression Standard | Baseline Profile / Main Profile / High Profile |
| Resolution | 5MP (2592×1944), 4MP (2592×1520), 2K (2560×1440), 3MP (2304×1296), 1080P (1920×1080), 720P (1280×720), D1, CIF, 480×240 |
| Main Stream | 5MP / 4MP / 2K / 3MP / 1080P / 720P (60Hz: 1 ~ 30fps 50Hz: 1~25fps) HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps 50Hz: 1~50fps) |
| Sub Stream | 720P/D1/CIF/480×240 (60Hz: 1 ~ 30fps 50Hz: 1~25fps) |
| Third Stream | D1/CIF/480×240 (60Hz: 1 ~ 30fps 50Hz: 1~25fps) |
| Bit Rate | 64 Kbps ~ 8 Mbps |
| Bit Rate Type | VBR / CBR |
| Audio Compression | G711A / U |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Perimeter Protection | Line crossing, region entrance/exiting/intrusion (human/motor vehicle/non- motor vehicle classification) |
| Statistics | Target counting by line/area, heat map |
| Exception Detection | Scene change, video blur and video cast detection |
| Face Detection | Face detection and face capture |
| Other Events | Abandoned/missing object detection, crowd density detection |
| Network | RJ45 |
| Video Output | No |
| Audio | 1CH audio input 1 CH built-in MIC |
| Storage | Built-in micro-SD card slot up to 256GB |
| Reset | Yes |
| Alarm | 1CH alarm input 1CH alarm output |
| Remote Monitoring | Web Browser / PVMS Plus / NVR / mobile APP |
| Web Browser | IE (plug-in required) / Google Chrome / Edge / Firefox / Safari |
| Online Connection | Support simultaneous monitoring for up to 10 users Support multi-stream real time transmission |
| Weight (net) | Approx. 0.65kg |
| Installation | Ceiling mounting Wall mounting |
| Certificate | CE, FCC |
| Environmental Protection | Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH (EC1907/2006) |
