Specifications
| Model | PLC-VD3200/PM |
|---|---|
| Operating System | Linux |
| Display Screen | 7-inch IPS touch screen |
| Display Resolution | 1024×600, brightness: 300 cd/m2 |
| Operation Method | Capacitive touch screen |
| Video Input | Max. 4CH videos can be viewed simultaneously |
| Network Input Resolution | 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Compression | H.265+ / H.265 / H.264 / MJPEG |
| Local Input | Built-in microphone |
| Local Output | Built-in speaker |
| Compression | G.711 (U/A) |
| Resolution | Up to 2MP |
| Frame Rate | NTSC: 30fps PAL: 25fps |
| Simultaneous Playback | Max.1CH |
| Linked IPC | Max. 16 CH |
| Linked Indoor Extensions | Max. 5 |
| Interface | RJ 45 100 Mbps self-adaptive Ethernet port×1 |
| Wireless Network | WiFi 802.11b / g / n |
| Protocol | TCP / IP, DHCP, DNS, NTP, etc |
| Incoming/Outgoing Bandwidth | 40/40Mbps |
| Audio | Built-in speaker and microphone, support noise suppression and echo cancellation |
| Storage | Built-in micro-SD card slot, up to 256GB |
| Reset | Yes |
| Alarm Input | 8CH |
| Wi-Fi | Yes, 2.4G Wi-Fi |
| Unlocking Button | Yes |
| RS 485 | Reserved |
| Power Output | DC12V 200mA (only available when DC12V power supply is used) |
| Power | DC12V/POE |
| Power Consumption | < 6W |
| Dimensions (mm) | 180.6 135.6 26.8 |
| Weight (net) | Approx.0.36kg |
| Installation | Wall mounting |
| Working Environment | -20°C ~50°C, Humidity: less than 95% (non-condensing) |
| Certificate | CE, FCC |
| Environmental Protection | Complies with Directive EU RoHS, REACH and WEEE |
