Specifications
| Model | PLC-426M-AU-DL3/PM |
|---|---|
| Image Sensor | 1/2.5 "CMOS |
| Image Size | 3200×1800 |
| Electronic Shutter | 1/4 s ~ 1/100000s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.008 lux @F1.6, AGC ON 0 lux with illumination on |
| Lens | 2.8mm@F1.6, Horizontal FoV: 104°, Vertical FoV: 55°, Diagonal FoV: 128° 3.6mm@F1.6, Horizontal FoV: 78°, Vertical FoV: 38°, Diagonal FoV: 94° |
| Focus | Fixed |
| Lens Mount | M12 |
| Day Night | ICR |
| Wide Dynamic Range | 120dB |
| BLC | Yes |
| HLC | Yes |
| Digital NR | Yes |
| S/N Ratio | ≥50dB |
| Angle Adjustment | Pan: 0°~360° Tilt: 0°~80° Rotation: 0°~360° |
| Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264 Sub / Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| H.265 Compression Standard | Main Profile@Level4.1 High Tier |
| Resolution | 6MP (3200×1800), 4MP (2688×1520), 1080P (1920×1080), 720P (1280×720), D1, VGA (640×480), 480×240, CIF |
| Main Stream | 60Hz: 6MP (1~20fps) / 4MP / 1080P (1~30fps) 50Hz: 6MP (1~20fps) / 4MP / 1080P (1~25fps) |
| Sub Stream | 720P/D1/VGA/CIF (60Hz: 1~30fps 50Hz: 1~25fps) |
| Third Stream | D1/480×240/CIF (60Hz: 1~30fps 50Hz: 1~25fps) |
| Bit Rate | 64 Kbps ~8Mbps |
| Bit Rate Type | VBR / CBR |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser |
| Audio Compression | G711A/U |
| ROI | Each ROI to be configured separately |
| Network | RJ45 |
| Video Output | No |
| Audio | 1CH audio input 1CH built-in MIC |
| Reset | Yes |
| Remote Monitoring | Web browser / Pollo PVMS / Mobile APP |
| Web Browser | IE (plug-in required) / Google Chrome / Edge / Firefox / Safari |
| Online Connection | Support simultaneous monitoring for up to 6 users Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, P2P, QoS |
| Interface Protocol | ONVIF |
| Storage | Network remote storage |
| Smart Alarm | Motion detection, SMD |
| Smart Event | Video Exception (scene change, video blur and abnormal color detection), line crossing/region intrusion detection (human/motor vehicle/non-motor vehicle classification), abandoned/missing object detection |
| General Function | Watermark, IP address filtering, video mask, heartbeat, system config backup, smart supplement light, corridor pattern |
| PoE | Yes (IEEE802.3af) |
| Supplement Light Range | IR range: 20 ~ 30 m white light range: 20 ~ 30 m |
| Ingress Protection | IP67 |
| SD Card | Support SD Card Up to 256GB |
| Security | Video encryption, firmware encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP |
| Power Supply | DC12V/PoE |
| Power Consumption | ≤6.5W |
| Storage Conditions | -30°C ~ 65°C (-22°F ~ 149°F), Humidity: less than 95% (non-condensing) |
| Operating Conditions | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: less than 95% (non-condensing) |
| Dimensions (mm) | 167.6 × 75 × 74.6 |
| Weight (net) | Approx. 0.45kg |
| Installation | Ceiling mounting wall mounting |
| Certificate | CE, FCC |
| Environmental Protection | Complies with Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH (EC1907/2006) |
