Specifications
| Model | PLC-51632H4/PM-8K |
|---|---|
| System OS | Embedded Linux |
| Video Compression | H.265S/H.265+/H.265/H.264 |
| Video IP Video Input | 32CH IPC input |
| Video Resolution | 16MP / 12MP / 9MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280×1024/960 P / 720P / 960H / D1 / CIF |
| Video Network Bandwidth | 320Mbps/320Mbps (incoming/outgoing) |
| Video Output | HDMITM1 : 3840×2160/1920×1080/1280×1024/1024×768 HDMITM2 : 1920×1080/1280×1024/1024×768 VGA×1 : 1920×1080/1280×1024/1024×768 VGA and HDMITM1 output the same video source |
| Multi-screen Display | Main output: 1/4/6/8/9/13/16/25/32/36 (live view) AUX output: 1/4/6/8/9 (live view) Max. 32+9CH local live view |
| Audio Network Input | 32 CH IPC audio input |
| 2-way Audio | RCA×1 |
| Audio Local Output | RCA×1 |
| Audio Compression | G.711 (U/A) |
| Record Resolution | 16MP / 12MP / 9MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280×1024/960 P / 720P / 960H / D1 / CIF |
| Record Frame Rate | NTSC: 30fps PAL: 25fps |
| Playback Simultaneous Playback | Max 16CH |
| Playback Search | Time slice / time / event / tag / smart search |
| Playback Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events |
| Playback Function | Play, pause, FF, FB, digital zoom, etc |
| Decoding Capability Live View/ Playback | Non-AI Mode: 1×16MP@30fps / 4×6MP@30fps / 9×2MP@30fps / 16×720P@30f ps AI Mode: 1×16MP@30fps / 4×5MP@30fps / 9×2MP@30fps / 16×720P@30fps |
| Alarm Mode | Manual, sensor, motion, exception, smart events, etc |
| Alarm Input | 16 CH local alarm input |
| Alarm Output | 4 CH |
| Alarm Triggering | Record, snap, preset, e-mail, etc |
| Face Detection Performance (AI by IPC) | 32CH |
| Face Detection Performance (AI by Device) | 2 CH (2MP) |
| Face Match Performance | 6 CH |
| Comparison Capability | 18 pictures / second |
| Face Picture Database | 32 libraries 10000 Face Pictures |
| Face Picture Search | Search by picture is supported |
| Database Management | Add, modify, delete and search face pictures |
| Face Picture Adding | Add face pictures through APP, WEB and external import |
| Face Picture Comparison | Support allow list, block list and stranger match alarm |
| Track | Track display on a map |
| Statistical Graph of Information | Bar graph |
| Statistical Mode of Information | Statistics by day, week, month, quarter as well as customized time period |
| Human/Vehicle Classification (AI by IPC) | 32 CH |
| Human/Vehicle Classification (AI by Device) | 2CH (2MP) |
| Human/Vehicle Attribute Analysis (AI by IPC) | Yes |
| Fisheye | Supports fisheye dewarping via NVR / Web Client / mobile APP |
| Plate Recognition (AI by IPC) | Yes |
| Interface | RJ 45 1000 Mbps×2 |
| Protocol | TCP / IP, HTTP, HTTPs, 802.1X, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP |
| Client Connection | Max.128 users access |
| OS | iOS, Andriod |
| HDD Interface | SATA×4, max 10T for each HDD |
| E-SATA Interface | E-SATA×1 |
| Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes |
| RS 485 | Yes (full-duplex), connect to PTZ or keyboard |
| USB | USB 3.0×1 USB 2.0×2 |
| Remote Controller | Optional |
| Power Supply | ATX 200W |
| Consumption | ≤ 20W (without HDD) |
| Certificate | CE, FCC |
| Environmental Protection | Directive EU RoHS, REACH and WEEE |
| Dimensions (mm) | 440×390×70 (W×D×H) |
| Working Environment | -10 ~ 50°C，10% ~ 90% humidity |
