Specifications
| Model | PLC-HS301 |
|---|---|
| Product model: | PLC-HS301 |
| Sensor Type | CMOS Sensor |
| Optics | 4mm，F2.6 aperture |
| Form Factor | Indoor PTZ Wi-Fi Camera |
| Product Colour | White |
| Antenna | Plug-in Antenna – White Copper |
| Materials | ABS |
| Surface Finishing | matte face |
| Dimension (L*W*H)(mm) | Ø 77*109mm |
| Viewing angle | D: 92°°*H: 78*V: 42° |
| Image circle | Ø6.9 |
| Dimension | M12*22.9mm； |
| Resolution | 2304*1296 Pixel |
| Night Vision | 10M distance |
| Sensory threshold | Colour cut black: 0.8Lux black cut colour: 8.5Lux |
| Working Indicator | Red and blue two-colour*1 |
| WIFI module | AB6032I |
| Mic | 4015/Full duplex, sensitivity: ≥-38±3dBm |
| Speaker | 2030 Oval 8Ω/1W |
| TF Card | Max support 128G |
| Button Switch | Reset*1 |
| Antenna | Plug-in Antenna – White Copper*1 |
| Horizontal angle | 352° |
| Vertical angle | 60° |
| Wifi Maximum rate | 54Mbps |
| Wifi distance | open distance ≥120米 |
| Wifi standard | IEEE 802.11 b/g/n, single frequency 2.4G |
| Power Supply | DC 5V |
| Operational power consumption | Max 4.5W |
| I/O Input port | TF Card*1, Mic*1, USB*1 |
| I/O Output port | Speaker*1； |
| I/O key type | Tact Switch*1 |
| I/O Indicator light | Red and green indicator light*1 |
| Video Format | H.264 |
| Video frame rate | Day：20fps； Night： 15fps; |
| Resolution & frame rate | HD：2304*1296 Pixel ；SD：1080*720 |
| Infrared night vision | 10 meters black and white night vision |
| Switch mode | Automatic |
| Andorid | Android 4.3+ |
| IOS | IOS 9.X+ |
| Mobile APP | Cloud Edge |
| Cloud platform | Amazon |
| Language | China, English, France, Germany, Italy, Spanish, Japan |
| Basic function | Support configuration / real-time preview / screenshot / playback / intercom / video adjustment / recording / PTZ / cloud storage / format SD card |
| Communication Protocol | WIFI |
| Online visitor | Max 5 user |
| Type of Alarm | Alarm |
| Motion Detection | Support |
| Mobile tracking | Support |
| Human Body Filtering | Support |
| Detection Sensitivity | Level 0-10, default 6 |
| Video tracking | Human Detection / Sound Detection |
| Remote control and monitoring | Support |
| Power failure memory | Support |
| Onvif | Optional |
| Pairing | QR code add, AP hotspot |
| Storage Class | Local storage, cloud storage |
| OTA upgade | Support |
| Blue light Slow flash | preview image |
| Blue light Always bright | Unreviewed image |
| Blue light Always bright | online |
| Blue light Slow flash | running normally |
| Red light Slow flash | The device enters this state when it is powered on and no network is configured。 Duration: Indicates the duration until the standby network exits |
| Red light Quick flash | Duration: Until the network is configured successfully |
| Blue light Quick flash | Until the upgrade succeeds or fails – (the green light is always on when the upgrade is successful) |
| Red light Red Quick flash | The network status is the same as device |
| Reset the device | Red light flashes slowly -> red light flashes quickly -> blue light is always on The red-light flashes slowly when the network is not configured. When the user connects to the 2.4G network and scans the code for the device, the red-light flashes quickly The red-light flashes quickly to indicate that the server is being connected the indicator is steady blue, the network is online successfully; |
| Restart the device | Red slow flash>red quick flash>blue light always on |
| Broken networke | Red Quick flash |
| USB Cable | 1.8m USB cable |
| Mounting bracket | White-Wall Bracket–Universal |
| Screw Kit | Packaging bag+ steel screw*2 |
| User Manual | English |
| Package | White box, blister, inner tray, carton； |
| Installation | Desktop, hanging, wall hanging |
| Temperature setting | Working： -20 ~ 60°C, Humidity <95% Storage：-25 ~ 65°C, Humidity <95% |
